| 相機類型 | camera type | CMOS | 互補金屬氧化物半導體 |
| 接觸時間 | exposure time | 1~30S（adjustable） | 1~30S（可調） |
| 監視器 | monitor | 43 inch screen（Optional mobile stand） | 43寸屏幕（可選配移動支架） |
| 電源類型 | power type | programmable power supply | 可編程電源 |
| 電壓范圍 | voltage range | 0~60V continuously adjustable (parameters can be customized) | 0~60V連續可調（參數可定制） |
| 電流范圍 | current range | 0~20A continuously adjustable (parameters can be customized) | 0~20A連續可調（參數可定制） |
| 缺陷類型 | defect type | High current: hidden cracks, chip fragments, low-efficiency cells, sintered grid lines, material defects, broken grids. Low current: low-efficiency cells. | “大電流：隱藏裂紋、芯片碎片、低效率電池、燒結柵線、材料 缺陷、破損柵格。 低電流：低效率電池?！?/span> |
| 軟件處理 | software processing | Zoom function, barcode display, local data query, integration with MES system， high current detection, low current detection, support for foot pedal triggering， ,scanner triggering, and overcurrent protection.
| 縮放功能、條碼顯示、本地?cái)?shù)據查詢、與MES系統集成、 高電流檢測、低電流檢測、支持腳踏板觸發、掃描儀觸發、過流保護。 |
| 電氣指標 | Electrical indicators | Electrical indicators | Electrical indicators |
| 錯誤報警 | error alarm | Real-time fault alarm | 實時故障報警 |
| 人機界面 | HMI | touch screen | 觸摸屏 |
| 工作環境 | working environment | Temperature: 25℃±10℃; relative humidity: ≤85% | 溫度：25℃±10℃； 相對濕度：≤85% |
| 電源 | power supply | AC220V/50Hz/15A | 交流220V/50Hz/15A |
| 壓縮的空氣 | compressed air | Air pressure: 0.5—0.8MPa, gas consumption: 0.3 m3/min | 氣壓：0.5—0.8MPa，耗氣量：0.3 m3/min |
| 設備尺寸 | Equipment size | 2890mm*2100mm*1420mm | 2890mm*2100mm*1420mm |
